Temperature Range: +25℃ to + 80℃ ±1℃
Humidity Range: Saturated Condition
20% to 98% ±3% variable as per test condition
Fog Collection: 0.5 to 2ml per hour
Control system: PID type OR Programmable Microprocessor based control system with touch screen for cyclic chamber
Systems & Control features: CFC free Hermetically sealed refrigeration system
Salt Spray Test: IS 9000, IS 5528, IS 6910, ASTM B 117, JIS 2371, UNICHEM, DIN ISO 9227
Performance: Condensed water test as per ISO 6270
CASS Test: ASTM B 368
CCT: PV 1210, VDA 621-415, SAE J 2334, NES CCT - I/II/1V, Renault D 17: 2008 ECC1, GMW 14872
| Model No. | Volume (Liters) | W (MM) | D (MM) | H (MM) |
|---|---|---|---|---|
| CCT-1000 | 1000 | 1500 | 850 | 800 |
| CCT-1500 | 1500 | 2000 | 1000 | 750 |
*Test Space can be provided as per customer requirement
*Appearance & Design of Chamber may vary depending on the internal dimension
*All performance measured at Room temperature / Ambient of ±25℃ to ±2℃
