Temperature Range:
Hot Zone: +50℃ to +220℃ ±1℃
Cold Zone: +50℃ to -80℃ ±1℃
Humidity Range (in Cold Zone) (Optional) : 20% to 98%, ±3% RH
Dew Point Range for Humidity test: +4℃ to +85℃
Climate Range for Humidity test: +25℃ to+85℃
Options: Humidity In Cold Zone.
| Model No. | Volume (Liters) | W (MM) | D (MM) | H (MM) |
|---|---|---|---|---|
| THS-27 | 27 | 300 | 300 | 300 |
| THS-90 | 90 | 450 | 450 | 450 |
| THS-200 | 200 | 600 | 600 | 600 |
*Test Space can be provided as per customer requirement
*Appearance & Design of Chamber may vary depending on the internal dimension
*All performance measured at Room temperature / Ambient of ±25℃ to ±2℃
Dual loop Microprocessor programmer, Touchscreen based HMI with ethernet facility.
• Unlimited real time recording of temperature measured values versus time (log on Pen Drive).
• Recordings in CSV format (Comma Separated Value) for easy export to Excel® to Pendrive via USB interface placed on the front panel.
• Cycles as per requirement can be programmed directly from the touchscreen.
• Remote Monitoring through PC on Ethernet with VNC. VNC will be free download version.
• Air cooled / Water cooled Semi Hermetic type. CFC free refrigeration system Performance Conform IS 9000, DEF-STD-133, IEC 68 Specifications
PID type controllers OR Microprocessor programmer, Touchscreen based control system with ethernet facility, Recorder. Air cooled / Water cooled / Semi Hermetic type CFC free refrigeration system.
Transfer Time: <10 Sec.
Performance: Conform IS 9000, JSS 55555, 50101, IEC 68, MIL- STD-202, 810, 883, DEF-STD-133 Specifications.
