Standard Test Space
RN (IS 9000 / JSS 55555)
RN (IS 9000 / JSS 55555)
| Model No. | Volume (Liters) | W (MM) | D (MM) | H (MM) |
|---|---|---|---|---|
| RN-1750 | 1750 | 1200 | 1200 | 1200 |
RN (JIS/IEC)
| Model No. | Volume (Liters) | W (MM) | D (MM) | H (MM) |
|---|---|---|---|---|
| RN-420 | 420 | 750 | 750 | 750 |
| RN-1000 | 1000 | 1000 | 1000 | 1000 |
*Test Space can be provided as per customer requirement
*Appearance & Design of Chamber may vary depending on the internal dimension
* All performance measured at Room temperature / Ambient of ±25℃ to ±2℃
Performance: Conform to IS 9000, JSS 55555, JIS D 0203, IS 12063, IEC 60529 (IP), DIN 40050 IP 1 TO 9K & ISO 20653 IP 1 TO 9K
IS 9000 /JSS 55555
Rain spray nozzles as per IS 9000 / JSS 55555. total 8 nozzles, four nozzles at the top four corners inclined at 45 degree and 4nozzles in the center of each four sides. Pressure Gauges for each nozzle. Rotameter to monitor rate, Rotating Table.
IS 12063 / IEC 60529 (IP)
Drip Test Setup as per IPX1/X2
Oscillating pipe formed in to a semi-circle with nozzles as per IP X3/4/4K
Jet Nozzle as per IP X5/6/6K/9K
JIS D 0203
Rotating nozzle and Rotating table as per JIS D 0203
Rotating Table will be provided with variable speed.
